BRESSER tripod head with precision adjustment MH-100 (polar wedge)

BRESSER Tripod Head with fine adjustment MH-100 (polar wedge)

Tripod head with fine adjustment for fast and exact polar height adjustment of the BRESSER StarTracker PM-100 astrophotography mount Art. No. 4964120.

The BRESSER tripod head with fine adjustment MH-100 allows a very precise adjustment by means of large knurled screws. However, in order to keep the adjustment paths of the knurled screws as small as possible, the mounting plate has a quick clamping device with serration that allows a coarse adjustment of the polar height (latitude at the location) to be selected. The MH-100 tripod head can be mounted on all photography tripods with 1/4 inch photo thread connection. The StarTracker astrophotography mount can be attached without tools to the MH-100 tripod head using the 1/4" photo thread screw. The complete tripod head is made of black anodized aluminum and, thanks to the use of solid material, guarantees maximum stability. The fine threaded knurled screws are even made of stainless steel and guarantee long durability and corrosion resistance.

Ideal for optimizing tracking accuracy in astrophotography.

NOTE: Can also be used as a sturdy adjustment element of a guide telescope in astrophotography. Parallel orientation of the main telescope and guide telescope is thus possible quickly and accurately. Base plate connection: 3 1/4 inch photo threads with a hole spacing of 35.0 mm. Mounting plate connection: 2 M8x1.25 threads with 35.0 mm hole spacing.

FEATURES

• Compact tripod head with precision adjustment
• Functions as a polar height wedge
• For precise adjustment of polar orientation
• Mounting plate with quick clamping device and serrations
• Can be used with all photo tripods and 1/4" photo thread connection
• Made of black anodized aluminum and stainless steel
• Easy and quick to use
• Suitable for BRESSER StarTracker PM-100 mount for astrophotography
• Suitable for BRESSER tripod TP-100 DX
• Ideal also as adjustment element of a guide telescope
• For parallel orientation of the main telescope and the guide telescope
• Base plate connection: 3 1/4" photo threads; hole spacing 35.0 mm.
• Mounting plate connection: 2 threads M8x1.25 mm; hole spacing 35.0 mm

• Tripod head with fine adjustment MH-100
• Operating instructions
