Clormic digital colorimeter

Clormic digital colorimeter

APPLICATIONS

Chemical laboratory, Quality control, Contamination control.

FEATURES

• Spectral range: from 400 to 800 nm, by means of 30 nm bandpass interferential filters. Manual filter selection by means of a 12-position disc.
• Standard position and filters of 420, 440, 490, 520, 550, 580, 620 and 680 nm.
• ABS range expanded from -0.3 to 3.5 O.D. in actual reading.
• Transmission reading: 0 to 100 T %.
• Photometric accuracy: >1%.
• Photometric accuracy: ±1%.
• Photometric stability better than 0.004 A/h.
• Light source: long-life tungsten lamp.
• Detector: solid state (silicon photodiode).
• Measuring cuvette: universal holder for 10 mm optical pitch cuvettes and for 12 and 16 mm Ø tubes.
• Minimum reading volume: 1 ml.
• Alphanumeric L.C.D. display with 2 lines of 20 characters.
• Calculation method: T % Transmission, Absorbance, Concentration with factor and Standard concentration. Internal calibration and adjustments by software.
• RS-232 connection

CONTROL PANEL

• Start-up switch.
• Alphanumeric display with interactive messages.
• Numeric and function keypad.

• BUILT-IN PRINTER: NO
• WEIGHT: 4.5Kg
• DIMENSIONS: 11x18x28cm
• CONSUMPTION: 10W
