Visible Range Spectrophotometer V-1100
Visible range spectrophotometer V-1100 for use in laboratories and educational institutions to perform experiments and quantitative analysis in general based on absorbance readings.
Carrier | Description | Estimated Delivery | ||
---|---|---|---|---|
Home delivery - International | Home delivery - International |
Thursday, 12 December - Thursday, 19 December |
Home delivery - International
Home delivery - International
Estimated delivery:
Thursday, 12 December - Thursday, 19 December
Visible Range Spectrophotometer V-1100
High quality photometric silicon diode detector and a 1200 lines/mm diffraction grating ensure high precision and accuracy. Equipped with digital display for easy reading. Easy to use automatic zero and target. Easy switching between transmittance, absorbance and concentration modes at the touch of a key. Sample compartment that can accommodate cuvettes from 5 to 100 mm pitch, with cuvette holder (optional). Pre-aligned design allows the user to conveniently change the halogen lamp.
Optional: A Windows® based software that can extend the applications in standard and kinetic curves.
MODEL V-1100:
- Simplicity and ease of use.
- Ergonomic and robust design for continuous use, suitable for workers and students.
Technical Specifications MODEL V-1100:
- Wavelength range: 325-1000 nm
- Spectral bandwidth: 5 nm
- Optical system: Single beam, diffraction grating 1200 lines/mm
- Manual spectral adjustment: Automatic
- Spectral accuracy: ±2 nm
- Spectral repeatability: 1 nm
- Photometric accuracy: ±0.3% T
- Photometric repeatability: ±0.3% T
- Photometric range: -0,3-3 A, 0-200% T. 0-9999 Concentration
- Stray light: 0.5% T
- Stability: ± 0.004 A/h @ 500 nm ± 0.002 A/h @ 500 nm
- LCD Display: 4 Digits 128x64 pixels
- Detector: Silent
- Sample compartment: Standard cuvette 10 mm pitch (100 mm optional)
- Illumination source: Tungsten lamp
- Data output: USB - Parallel port (printer)
- Power supply voltage: 220 V / 50 Hz AC or 110 V / 60 Hz AC
- External dimensions (Height, width, depth): 160 x 480 x 360 mm
- Weight (Kg): 8
ACCESSORIES:
Flow cuvette, 5 to 100 mm cuvette holder, cuvette holder, refrigerated cuvettes and tube holder.
Visible Range Spectrophotometer V-1100
