M15 4G IR 940 nm HIKMICRO M15 4G IR 940 nm Phototrap Camera

The HIKMICRO M15 is a powerful and rugged photo trapping camera with 4G network. It can be triggered by animal movement with a highly sensitive passive infrared (PIR) motion sensor with a detection range of up to 25 meters. It is capable of taking photos and recording videos in true vivid colors during the day and black and white images or video clips at night.

Photos and videos captured with the M15 photo trapping camera can be sent to a smartphone via 4G cellular network anytime, anywhere. It features a ruggedized housing, high-reliability design and ultra-low power settings that allow it to operate outdoors for several months.

MAIN CHARACTERISTICS

• Transmission of photos and video clips via 4G network
• 10MP images and 1080p video with audio capture
• Triggering speed of 0.5 s
• PIR detection range of 25 meters
• Comprehensive yet easy-to-use functions via the HIKMICRO Sight application

TECHNICAL SPECIFICATIONS

MOBILE

• Network: 4G
• SIM card: Single SIM card (integrated in the camera)
• Photo capture and transmission: Yes
• Video recording and transmission: Yes

PHOTOS

• Image resolution: Up to 10M (4240 * 2385)
• Thumbnail resolution: 640 × 360, JPG
• Image format: JPG
• Burst shooting: Support 1/2/3 pictures per detection
• Capture modes: Color during daytime, black and white during nighttime
• Watermark: Logo, battery capacity, moon phase, temperature (°C/°F), date and time

VIDEOS

• Video resolution: 1080P (1920 × 1080); 720P (1280 × 720); WVGA (848 × 480)
• Thumbnail resolution: 640 × 360, JPG
• Video format: MP4
• Video duration: 10 s (1080P)/20 s (720P)/30 s (WVGA)
• Audio recording: Yes

DETECTION SYSTEM

• Firing speed: 0.5 seconds
• PIR detection range: 25 meters
• PIR detection angle: 60° diagonal, 45°horizontal (20 m wide)
• IR LEDS: 12 LEDS / 940 nm

POWER SUPPLY

• Battery type: Standard AA batteries(not included). It works with 6 or 12 units.
• Autonomy: Up to 6 months (using 12 AA batteries)
• External power supply: DC port 12 V/2 A

MEMORY

• Local memory card: Supports SD card from 8 to 32 GB(not included); 32,800 HD images or 18,240 videos with 32GB memory card.
• Cloud album: Unlimited storage, but the exact number of thumbnails, photos and HD videos and the storage period vary according to different data plans.

SIGHT APP FEATURES

• APP functions: Camera settings, camera status, data and plan consumption control, photo and video reception and transmission settings, photo and video browsing and category management.
• Free data plan: 100 images per month with 30 days expiration. You can choose other data plans through the HIKMICRO SIGHT application.

*Synchronization with the app is not available in Andorra

GENERAL

• Storage temperature: -25°C to 60°C (-4°F to 140°F)
• Operating temperature: -20°C to 55°C (-4°F to 140°F)
• Supported humidity: 5% to 90%
• Protection level: IP66
• Dimensions: 112 mm × 86.4 mm × 143 mm
• Weight: 440 grams
• Accessories: Installation strap, SIM card, antenna, USB cable, QSG
• Mounting adapter: 1/4″-20-UNC

Data Plans

• All the information and contracting of the plans can be found in the SIGHT APP.

FREE PLAN
100 free photos per month. Images are stored in the cloud for 30 days, after which they are automatically deleted.

BASIC PLAN
300 photos per month. The monthly cost is 5€ (20% discount if you sign up for the whole year). The images are stored in the cloud for 365 days, after which they are automatically deleted.

PREMIER PLAN
800 photos per month. The monthly cost is 8€ (25% discount if you sign up for the whole year). The images are stored in the cloud for 365 days, after which they are automatically deleted.

SUPREME
Unlimited photos. The monthly cost is 13€ (30% discount if you contract the whole year). Images are stored in the cloud for 365 days, then automatically deleted.

PHOTO AND VIDEO PACKAGES

HD PHOTO PACK
50 photos for 5€. Unlimited cloud storage.

HD VIDEO PACK
10 videos for 5€. Unlimited cloud storage.

Box contents

• M15 photo trapping camera
• USB cable
• Antenna
• Installation strap
• SIM card
• Quick Start Manual
