Multiple illumination options offer the ability to view objects under magnification under normal external illumination sources, such as white light or near infrared, or ultraviolet illumination, simply switching from one to the other. Infrared can be used in document examination and the new enhanced ultraviolet system provides improved fluorescence contrast for use in forensic, biomedical or electronic vision applications.
Working distance/field of view/ depth of field:
| MAGNIFICATION RATE |
WORKING DISTANCE* |
FIELD OF VIEW(X) |
FIELD OF VIEW(Y) |
DEPTH OF FIELD |
|
60. |
19.5 |
15. |
2.5 |
|
33.5 |
|
10. |
1. |
|
20. |
9. |
7. |
1.5 |
|
13. |
7. |
6. |
|
|
9. |
6.5 |
5. |
|
|
7.1 |
5. |
4.5 |
1.0 |
|
5.5 |
4. |
3. |
|
| 90 |
4.5 |
4. |
3.5 |
|
|
4.1 |
3. |
3.1 |
|
| 110 |
|
3. |
2. |
|
|
4.1 |
3. |
2. |
|
|
4.5 |
|
2. |
|
|
5 |
2. |
2. |
|
|
5. |
2. |
2.1 |
|
|
6. |
2. |
|
|
| 170 |
7.1 |
2. |
1. |
|
|
|
2. |
1. |
|
|
8. |
2.1 |
1. |
|
|
9. |
|
1. |
|
|
10. |
1. |
1.5 |
|
| 220 |
11. |
1. |
1. |
0.1 |
| Listed values may differ slightly |
|
|
|
Unit = mm |
Specification
| Lighting |
| Light/ LED type |
~395 nm UV + ~940 nm Infrared |
| Number of LEDs |
4+4 |
| LED on/off switchable: |
Yes |
| Infrared filter |
No |
| Diffuser available |
No |
| Emission filter |
No |
| Polarizer |
No |
| Optics |
| Magnification |
20-220x |
| Macro zoom |
No |
| Working distance |
Standard |
| Lens type |
Glass with anti-reflection coating |
| Sensor |
| Sensor type |
CMOS |
| Resolution |
1.3 Megapixel (1280×1024) |
| Maximum frame rate |
30 fps |
| Compatibility |
| Interface |
USB 2.0 |
| Operating system |
Windows 7, 8, 10 & 11, MacOS 10.9 and up |
| Included software |
DinoCapture 2.0 (Windows), DinoXcope (Mac OS) |
| Supported image formats (Windows) |
BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX, PGX, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX |
| Supported video formats (Windows) |
WMV, FLV, SWF |
| Supported image formats (MacOS) |
JPEG, PNG |
| Supported video formats (MacOS) |
MOV |
| Imaging standards |
DirectShow, UVC |
| Wifi |
Wireless-ready, requires the WF-10 WiFi streamer (optional) |
| Housing |
| Housing material |
Composite/ plastic housing |
| Magnification lock |
Yes |
| Dimensions |
10.5cm (L) x 3.2cm (D) |
| Weight |
105g |
| Cable length |
1.8m |
| Features |
| Special feature |
No |
| Measurement |
Yes |
| Calibration |
Yes |
| Microtouch sensor |
Yes |
| ESD safe |
No |
| Information |
| Package contents |
Microscope, carry pouch, software CD, calibration target, user manual |
| Warranty information |
2 years European warranty |
| Regulatory approval |
CE, FCC, ROHS, ROHS, UKCA - available upon request - |
