Baader SII 6.5nm 2" filter optimized for CMOS

This new generation of CMOS filters from Baader features:

  • Increased contrast
  • Ever narrower passbands
  • Reflex-Blocker™ coatings, for largest ever freedom from halos, even under most adverse conditions concerning aux-optics
  • FWHM on each filter category carefully designed to allow for 1:1:1 exposures, matched for typical CMOS quantum efficiency and s/n ratio
  • Identical filter thickness to existing standards, with utmost care for parfocality
  • Blackened edges all around, with filter-lead-side-indicator in the form of a black frontside outer rim, to additionally eliminate any reflection due to light falling onto the edge of a filter
  • Each filter individually coated, with sealed coating edge (NOT cut out of a larger plate with coatings left exposed, read more)
  • Life-Coat™: evermore hard coatings to enable a non-aging coating for life - even in a most adverse environment
General features
  • 2 "x 2 mm Baader S-II narrow band filter - Precision grade - with 2" (M48) filter thread
  • 6.5 nm FWHM, recommended for f / 10 af / 3.5" optical systems
  • Reflex-Blocker ™ hard-coated and planoptically polished, with sealed coating edges (Life-Coat ™)
  • Blackened edges all around, with filter lead-side indicator in the form of black outer edge on the front side
  • Optimized for modern CMOS cameras, but excellent for CCD camera technologies
  • Mounted on Baader Low Profile Filter Cell (LPFC) - 6 mm high
Technical Specifications:
  • SKU (#) 2961253
  • EAN CODE 4047825047366
  • WEIGHT (KG) 0.07
  • COLOR Black
  • Transmission Range S-II
  • FILTER THICKNESS (without cell) 2 mm
  • BANDWIDTH 6.5 nm
  • CWL (CENTRAL WAVELENGTH) 671.7 nm
  • AR-COATING Reflex-Blocker™ anti-scratch coating, planoptically polished
  • 2" diameter
  • FILTER USE: CMOS, CCD, S-II
  • MOUNTING Mounted (LPFC 6mm)
  • FILTER TYPE Narrowband, Narrowband
  • FILTER SHAPE Round with threaded cell

Baader SII 6.5nm 2" filter optimized for CMOS
