Crayford Dual Speed Low Profile OMEGON Steeltrail 2" focuser for Newton

Crayford Dual Speed Low Profile OMEGON Steeltrail 2" focuser for Newton

would you like to upgrade your equipment with a better quality eyepiece holder and always find the perfect focus point? With the new Crayford Steeltrail eyepiece holders from Omegon you improve your equipment and get high focusing accuracy. Its stainless steel bearing system provides a long service life.

• Exclusive Crayford 2" focuser with stainless steel ball head
• Indestructible: Stainless steel parts for long service life
• 1:10 reduction to find the perfect focus
• Large carrying capacity for all accessories
• Compatible with telescopes Skywatcher by means of an adapter
• Anti-reflection grooves for higher contrast

do you have a telescope with a single eyepiece holder? If you look closely at the bearing of the single eyepiece holder you will see that it leaves a groove in the delicate aluminum of the inner tube. Do you expect such a part to serve you for many years to come? If you are one of those who place importance on precision and accuracy, you will not be very happy with this eyepiece holder? The time has come to upgrade your equipment.

Steeltrail - Stainless steel bearings
All important parts of the Omegon Steeltrail eyepiece holder are made of stainless steel. The V2A bearings run on stainless steel wheels, giving the eyepiece holder greater precision. The heavy loads over a long period of time are also no problem for this eyepiece holder. The ball-and-socket joint head prevents unbalance and keeps the part in good working order for years.

1:10 reduction - Perfectly sharp objects
When enlarging images and trying to take astrophotographs it is difficult to find the perfect focus point. However, thanks to the 1:10 reduction setting, it is possible. Turning the steel wheel moves the 2" tube by one tenth of a millimeter, so if we turn the wheel half a turn, we will have varied the focus travel by about one millimeter.

load capacity up to 5 kg!
A special advantage of this eyepiece holder is its great weight-bearing capacity, as it is capable of supporting heavy eyepieces and cameras. In addition, since it has no clamps, it can be moved freely without the 2" tube slipping, which is taken care of by the great finish of the part.

Simple attachment to Newtonian telescope

The eyepiece holder can be attached to the appropriate filter by means of an 80 mm diameter ring. Many amateur astronomers have a telescope Skywatcher that they want to complement and improve. They used to have a major drawback: There were no adapters of a compatible size. Now, however, with this additional adapter from Omegon you can make the eyepiece holder compatible with Skywatcher equipment in as little as 3 minutes.

Omegon Steeltrail eyepiece holder

The Omegon Steeltrail collection consists of three models:

• Crayford for Newton telescopes
• Crayford for SC telescopes and similar designs
• Helical focuser for Newton telescopes

And you, when are you going to equip your telescope with a professional quality eyepiece holder?

Technical specifications:

• Suitable for...Newton telescopes
• Connection: 2
• Reduction: 1:10
